Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304

Ask Lasest Price
Brand Name :	TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Model Number :	304L hot rolled/cold rolled stainless steel coil
Price :	negothiable
Payment Terms :	L/C, T/T
Supply Ability :	2000T PER MONTH OR MORE
Delivery Time :	15-20 days after deposit
Certification :	mill certificate

Add to Cart

Product Details
Company Profile

Din 1.4305 301 Stainless Steel Coil 20-610mm 201 304 316 409 201 304

304L hot rolled/cold rolled stainless steel coil

304L is the low carbon version of 304. It is used in heavy gauge components for improved weldability. 304L has a carbon maximum is 0.030. Austenitic Cr-Ni stainless steel. Better corrosion resistance than 302. High ductility, excellent drawing, forming, and spinning properties. Essentially non-magnetic, becomes slightly magnetic when cold worked. Low carbon content means less carbide precipitation in the heat-affected zone during welding and a lower susceptibility to intergranular corrosion. Applications include beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing.

ElementType 304L (Wt.%)

Carbon: 0.03 max

Manganese: 2.00 max.

Phosphorus: 0.045 max.

Sulfur: 0.030 max.

Silicon: 1.00 max.

Chromium: 18.00-20.00

Nickel: 9.00-12.00

Element (Wt.%)

Carbon	Manganese	Phosphorus	Sulfur	Silicon	Chromium	Nickel
0.03max	2.00max	0.045max	0.030max	1.00max	18.00-20.00	9.00-12.00

Mechanical Property

Material Item	Tensile Strength (MPa)	Yield Strength (MPa)	Extension	Hardness (HV)	Density
304L	≥480	≥175	≥40%	≤200	7.93g/cm³

Surface Treatment

Surface Treatment	Definition	Application
NO.1	A hot - rolled piece whose surface has been treated by heat treatment, pickling or the corresponding process	Chemical Tanks, Pipes, Chemical Industry Equipment etc.
2B	After cold rolling, heat treatment, pickling or other equivalent treatment, the final cold rolling to give appropriate luster	Medical Equipment, Food Industry, Construction Material, Kitchen Utensils etc.
BA	After cold rolling, bright heat treatment is given	Kitchen Utensils, Electric Equipment, Building Construction etc.
NO.4	Products polished with abrasives 150 to 180 as specified in JIS R6001	Kitchen Utensils, Building Construction, Medical Equipment etc.
HL	After polishing, use the appropriate abrasive size to form a continuous polishing streak	Building Construction etc.
8K	A mirror-like reflective surface given by polishing with finer abrasives over 800 mesh	Reflector, Mirror, Interior and exterior decoration etc.

COIL

Commodity	304L hot rolled/cold rolled stainless steel coil
Brand	TISCO, ZPSS, BAOSTEEL, POSCO, JISCO, LISCO, etc
Surface	No.1/ 2B/ BA/ No.4/ 8K/ HL
Thickness	0.3mm-16mm
Width	1000mm-2000mm, or as customized
Length	as customized
Application	beer barrels, bellows, chemical equipment, coal hopper linings, cooling coils, cryogenic vessels, dairy equipment, evaporators, feedwater tubing, flexible metal hose, food processing equipment, hypodermic needles, nuclear vessels, oil well filter screens, refrigeration equipment, paper industry, pressure vessels, sanitary fittings, valves, shipping drums, spinning, still tubes, textile dyeing equipment, tubing
Delivery Time	Normally within 15 days, according to the quantity
Price Terms	FOB/ CFR/ CIF
Package	Standard Export Packaging

FAQ

Q1:What product information must I provide before making a purchase?

Please provide the grade, width, thickness, and surfacetreatment requirements, cold or hot ,as well as the quantities you require.

Q2:What shipping ports are there?

We normally ship from Shanghai,which is very near to my company , if you have other ports requirement, you could tell us in advance

Q3:What are your payment terms?

30% T/T in advance and 70% balance before shipment or LC at sight.

Q4:What about product pricing information?

Prices vary due to changes in raw material prices on a regular basis.

Q5:Is it possible to send samples?

Of course, we offer free samples and express shipping to customers all over the world.
Q6:Do you offer a service for customized products?

Yes, we can produce according to your specifications and drawings.

Q7:Can I pay you a visit at your factory?

Customers from all around the world are welcome to visit our factory.

Q8:Can you assist me in importing steel products for the first time?

Yes, we have shipping agent who will arrange the shipment with you.
